:boost_requested: Can anyone recommend an antenna to plug into ESP32 modules?

I mean the kind pictured, I like to be able to place the antenna outside my enclosure.

The datasheet specifies w.fl, mhf III from ipex, or AMC. I picked amazon.com/dp/B07R21LN5P as a cheap guess since it says u.fl ipex but it won't fit and amazon corrects w.fl to u.fl...

Unfortunately the recommended TFPD08H10060011 is not something I can find to buy.

Asking for part numbers if anyone has done this before.

#esp32

A rendering of the top of an ESPRESSIF ESP32-C3-MINI-1U microcontroller module. It shows an antenna port at the top left.
A datasheet for the ESP32-C3 showing the dimensions of the external antenna connector. There is a mechanical drawing in the middle showing the antenna connector. Text above the drawing says: ESP32-C3-MINI-1U uses the third generation external antenna connector as shown in Figure 10-3 "Dimensions of External Antenna Connector". This connector is compatible with the following connectors: • W.FL Series connector from Hirose • MHF III connector from I-PEX • AMC connector from Amphenol DRAWING The external antenna used for ESP32-C3-MINI-1U during certification testing is the third generation monopole antenna, with material code TFPD08H10060011. The module does not include an external antenna upon shipment. If needed, select a suitable external antenna based on the product’s usage environment and performance requirements. It is recommended to select an antenna that meets the following requirements: • 2.4 GHz band • 50 Ω impedance • The maximum gain does not exceed 2.33 dBi, the gain of the antenna used for certification • The connector matches the specifications shown in Figure 10-3 Dimensions of External Antenna Connector
